| Manufacturer | Vibro Meggitt |
| Series |
CI185 |
| Short Description |
Vibration Acceleration sensor |
|
Origin |
US |
|
Signal conditioner |
IP67 |
|
Supply Voltage |
12-30 V DC (24 V DC recommended) |
|
Temperature range |
−40 to 85 °C |
| Condition |
In Stock New & Original |
| Lead Time |
3-7 days |
|
Warranty |
12 monthes |
| Courier | Fedex/DHL/Your forwarder |
| Payment | T/T Multiple Currency Prepayment acceptable |
| Document | Available |
brand:
vibrationMEGGITT CI185
Vibration Acceleration sensor
The Vibro CI185 is an industrial-grade 4-20mA vibration accelerometer designed for rotating machinery vibration monitoring. It features a 2Hz-1kHz wideband frequency response and IP67 protection, supporting predictive maintenance in harsh environments ranging from -40°C to +85°C.
I. Basic Parameters
Measurement Type
Vibration acceleration (RMS velocity output)
Measurement Range: 0-20 mm/s (typical, customizable)
Signal Output
Current Output: 4-20 mA DC (linearly proportional to vibration velocity)
Load Capacity: ≤500 Ω
Frequency Response
Effective Range: 2 Hz to 1 kHz
Low-Frequency Cutoff: -3 dB @ 2 Hz (high-pass filter)
II. Environmental Adaptability
Operating Temperature: -40°C to +85°C
Protection Rating: IP67 (dust and water-resistant)
Shock Resistance: 100 g @ 11 ms (IEC 60068-2-27)
Vibration Resistance: 10 g RMS (2 Hz-1 kHz)
III. Electrical Characteristics
Supply Voltage: 12-30 V DC (24 V DC recommended)
Power Consumption: ≤2 W (at full scale)
Isolation Voltage: 500 V AC (between signal and housing)
IV. Mechanical Design
Housing Material: 316 stainless steel (corrosion-resistant)
Mounting Method: M10 threaded mount (standard, magnetic base optional)
Weight: Approximately 350 g
Cable Interface: M12 x 1 waterproof connector
V. Application Scenarios
Rotating Machinery Monitoring (Pumps, Fans, Motors)
Gearbox Vibration Analysis
Industrial Predictive Maintenance System (Compatible with mainstream platforms such as EPRO and Bently)
Frequently Inquired model：
144-280-000-215
144-280-000-125
144-280-000-015
Related :
TQ401 EA401
| Relevant Products we have | Model | PN |
| Racks | ABE04x | |
| Racks | ABE056 | |
| Analog monitoring card pair | AMC8 and IOC8T | |
| Calibrator Module | ACM215 | 204-215-000-101 |
| Acceleration Sensor | AS-022/050 | |
| Piezoelectric accelerometer | CA202 |
144-202-000-203 144-202-000-105 144-202-000-203 144-202-000-205 |
|
Piezoelectric accelerometer with integrated electronics |
CE134 CE310 CE620 CE110 |
444-134-000-145 444-620-000-011-A1-B100-C01 444-620-000-011-A2-B100 110-100-CT-VO-S 110-100-CT-VO |
| Piezoelectric pressure transducer |
CP232 CP237 CP502 CP104 |
143-232-000-222 143-502-000-021 143-502-000-031 143-502-000-041 143-502-000-051 143-502-000-061 143-104-000-101 |
| CPU card and input/output card. | CPUM and IOCN |
209-595-067-121 209-595-031-111 200-566-000-111 200-566-000-012 |
|
Rack controller and communications interface card pair. |
CPUR and IOCR | |
|
Rack controller and communications interface card pair. |
CPUR2 and IOCR2 | 600-026-000-002 |
| Velocity transducer | CV213 | 110-213-000-012 |
| Extension cable |
EA401 EA402 EA403 EA902 |
913-403-000-012 913-402-000-013 913-902-000-011 |
|
Accessory of EW140 and DIC413 ice-detection system for gas turbines |
EC119 EC222 |
922-222-000-002 |
| cable assembly | EC175 | |
| cable assembly | EE139 | |
| ice-detection sensor | EW140 | |
| Galvanic Isolation Unit | GSI130 | |
| Input/Output card | IOC16T | 200-565-000-013 |
| Input/output card for the CPUR2 | IOC-R2 | 620-022-000-112 |
| Intelligent relay card | IRC4 | 601-001-001-003 |
| Signal conditioner | IPC704 |
244-704-000-042 IPC704 244-704-000-511 |
| Signal conditioner | IQS450 IQS452 |
204-450-000-001 204-450-000-002 204-452-000-011 204-452-000-211 |
| Signal conditioner | IQS900 | 204-900-000-011 |
| Machinery protection card | MPC4 |
200-510-150-011 200-510-041-022 200-510-150-031 200-510-070-113 200-510-078-115 |
| Machinery protection card | MPC4G2 and IOC4G2 | |
| Level Detector&Digital Display Module | PLD772 | 254-772-000-224 |
| Rack power supplies | RPS6U |
200-582-200-021 200-582-300-013 200-582-500-013 200-582-500-021 200-582-600-013（DC） |
| Relay card | RLC16 | |
| Proximity sensor |
TQ401 TQ402 TQ403 TQ412 TQ422 |
111-401-000-013 111-402-000-012 111-402-000-013 111-403-000-013 111-412-000-012 111-412-000-013 111-422-000-01 |
| Transmitter | TSW101M1 VMD-TSW101-M1-001-X007-Y02-H10 | |
| Tracking Filter | TFM677 | 204-677-000-003 |
| Condition monitoring card pairs | XMx16 and XIO16T | 620-002-000-113 |
| Condition monitoring module | XMV16 | 620-001-001-116 |
All VM products should be available in our expanded inventory, welcome to inquire:
sales23@htechplc.com
Kelly wang
+86 18150137569
