| Manufacturer | Vibro Meggitt |
| Series |
CE620 444-620-000-011-A1-B100-C01 |
| Short Description |
piezoelectric accelerometer with integrated electronics |
|
Origin |
Sweden |
|
Measurement range
|
5 mA (corresponding to 2 or 4 mm)
|
| Dynamic calibration |
5 to 3000 Hz
|
|
Temperature ranges
|
−40 to 125 °C |
| Condition |
In Stock New & Original |
| Lead Time |
12 weeks |
|
Warranty |
12 monthes |
| Courier | Fedex/DHL/Your forwarder |
| Payment | T/T Multiple Currency Prepayment acceptable |
| Document | Available |
brand:
vibrationVIBRO CE620 444-620-000-011-A1-B100-C01
piezoelectric accelerometer with integrated electronics
CE620 444-620-000-011-A1-B100-C01
The CE620 is a piezoelectric accelerometer using IEPE integrated electronics technology. It is designed for vibration monitoring and protection of industrial equipment (such as compressors and electric motors). It features a wide frequency response (0.5Hz-10kHz), high sensitivity (100mV/g), and an IP67 rating, making it suitable for use in harsh industrial environments.
Basic Specifications
Model Identification: CE620-444-620-000-011-A1-B100-C01 (Includes cable length, connector type, and other coding information)
Sensor Type: Piezoelectric Accelerometer (IEPE with Integrated Electronics)
Measuring Axis: Uniaxial (perpendicular to the mounting surface)
Performance
Measurement Range
Acceleration Range: ±50g (peak)
Velocity Range: 0-20mm/s (RMS, requires integration circuit)
Frequency Response
Effective Bandwidth: 0.5Hz to 10kHz (±3dB)
Resonant Frequency: >28kHz
Sensitivity
Nominal Value: 100mV/g (typical, @160Hz)
Tolerance: ±5% (after calibration)
Electrical Characteristics
Power Supply Requirements
Constant Current Source: 2-10mA (4mA recommended)
Voltage Range: 18-30VDC (subject to loop impedance requirements)
Output Signal
Dynamic Range: ±5V (full scale)
Output Impedance: <100Ω
Environmental Adaptability
Operating Temperature
Standard: -40°C to +120°C
High-Temperature Option: Extended to +180°C (customizable)
Protection Rating
Enclosure: IP67 (dustproof and waterproof)
Shock Resistance: 5000g (0.5ms half-sine wave)
Mechanical Characteristics
Mounting Method
Threaded Mounting: M5×0.8 or 1/4-28 UNF
Flatness: <0.001mm (mounting surface)
Physical Parameters
Weight: Approximately 28g (including cable connector)
Material: Titanium alloy housing (corrosion-resistant)
Certifications and Standards: Complies with ISO 10816 mechanical vibration assessment standards
CE/ATEX explosion-proof certification (specific model required)
ORRDERING INFORMATION
Part Number
(P/N)
Length L
in mm
144-306-000-111
3000 ± 100
144-306-000-121
6000 ± 150
144-306-000-131
9000 ± 200
144-306-000-141
12000 ± 200
