PLC SYSTEM GE DS200DTBAG1A GE Digital Contact Terminal Board

DS200DTBAG1A GE Digital Contact Terminal Board


  • item no.:

    DS200DTBAG1A
  • brand:

    General Electric
  • product details

DS200DTBAG1A

GE Digital Contact Terminal Board


  • Basic Info: Manufactured by General Electric, it’s a digital contact terminal board (functional acronym: DTBA) in the Mark V/Mark V LM DS200 series, for industrial automation, especially turbine control systems .
  • Core Function: Terminates digital contact inputs 1-46, connects signal wires to control panels, handles digital signals, and enables fail-safe configuration via TCDA board .
  • Key Specs: 2 terminal blocks (max 95 wires each, 190 total), 5 jumpers, 2 2-pin connectors; 24-125 VDC input voltage .
  • Compatibility & Features: Works with common data/digital I/O cores; -40°C to +85°C operating temp (varies by source); optically isolated inputs with timestamping .
Picture of DS200DTBAG1A



Below All avaiable in stock
