vibrationVIBRO CP232 Piezoelectric Pressure Transducer
The CP232 is a key model in Meggitt's Vibrometer CP series of piezoelectric pressure sensors, designed for dynamic pressure measurement in extreme industrial environments. It is specifically designed for dynamic pressure measurement and is particularly well-suited to extreme industrial environments.
Output Type: Charge Signal. This output is proportional to the dynamic pressure. For sensitivity, refer to the specific model's datasheet; the CP232 is considered highly sensitive.
Temperature Range: -54°C to 650°C (typical). Like other models in the CP series (such as the CP103 and CP211), it supports extreme high and low temperatures, suitable for high-temperature applications such as industrial furnaces and combustion chambers.
Frequency Response Range: 2 Hz to 10,000 Hz (typical). It covers the requirements for dynamic pressure measurement at medium and high frequency levels and is suitable for real-time pressure monitoring in equipment such as hydraulic systems and turbomachinery.
Insulation resistance: To ensure optimal performance, it must meet the minimum value specified in the acceptance test report (ATR). Use a megohmmeter (100 VDC ± 5% test voltage) to test at room temperature (+23 ℃ ± 5 ℃) before installation. Ensure that Rx (positive pole - shell), Ry (negative pole - shell), and Rz (positive pole - negative pole) meet the specified standards for proper sensor function.
Image of CP232
A
Pressure Measurement Chain
CPXXX piezoelectric pressure sensor
IPC707 signal conditioner/IPC704 signal conditioner
GSI127 electrical isolation unit
ECxxx cable
JB116 junction box
ABA17x and ABA160 industrial housings
K209 and K210 cables
K309 and K310 cables
APFxxx power supplies
ASPS auxiliary sensor power supply
Related Module:
| Relevant Products we have | Model | PN |
| Racks | ABE04x | |
| Racks | ABE056 | |
| Analog monitoring card pair | AMC8 and IOC8T | |
| Calibrator Module | ACM215 | 204-215-000-101 |
| Acceleration Sensor | AS-022/050 | |
| Piezoelectric accelerometer | CA202 |
144-202-000-203 144-202-000-105 144-202-000-203 144-202-000-205 |
|
Piezoelectric accelerometer with integrated electronics |
CE134 CE310 CE620 CE110 |
444-134-000-145 444-620-000-011-A1-B100-C01 444-620-000-011-A2-B100 110-100-CT-VO-S 110-100-CT-VO |
| Piezoelectric pressure transducer |
CP232 CP237 CP502 CP104 |
143-232-000-222 143-502-000-021 143-502-000-031 143-502-000-041 143-502-000-051 143-502-000-061 143-104-000-101 |
| CPU card and input/output card. | CPUM and IOCN |
209-595-067-121 209-595-031-111 200-566-000-111 200-566-000-012 |
|
Rack controller and communications interface card pair. |
CPUR and IOCR | |
|
Rack controller and communications interface card pair. |
CPUR2 and IOCR2 | 600-026-000-002 |
| Velocity transducer | CV213 | 110-213-000-012 |
| Extension cable |
EA401 EA402 EA403 EA902 |
913-403-000-012 913-402-000-013 913-902-000-011 |
|
Accessory of EW140 and DIC413 ice-detection system for gas turbines |
EC119 EC222 |
922-222-000-002 |
| cable assembly | EC175 | |
| cable assembly | EE139 | |
| ice-detection sensor | EW140 | |
| Galvanic Isolation Unit | GSI130 | |
| Input/Output card | IOC16T | 200-565-000-013 |
| Input/output card for the CPUR2 | IOC-R2 | 620-022-000-112 |
| Intelligent relay card | IRC4 | 601-001-001-003 |
| Signal conditioner | IPC704 |
244-704-000-042 IPC704 244-704-000-511 |
| Signal conditioner | IQS450 IQS452 |
204-450-000-001 204-450-000-002 204-452-000-011 204-452-000-211 |
| Signal conditioner | IQS900 | 204-900-000-011 |
| Machinery protection card | MPC4 |
200-510-150-011 200-510-041-022 200-510-150-031 200-510-070-113 200-510-078-115 |
| Machinery protection card | MPC4G2 and IOC4G2 | |
| Level Detector&Digital Display Module | PLD772 | 254-772-000-224 |
| Rack power supplies | RPS6U |
200-582-200-021 200-582-300-013 200-582-500-013 200-582-500-021 200-582-600-013（DC） |
| Relay card | RLC16 | |
| Proximity sensor |
TQ401 TQ402 TQ403 TQ412 TQ422 |
111-401-000-013 111-402-000-012 111-402-000-013 111-403-000-013 111-412-000-012 111-412-000-013 111-422-000-01 |
| Transmitter | TSW101M1 VMD-TSW101-M1-001-X007-Y02-H10 | |
| Tracking Filter | TFM677 | 204-677-000-003 |
| Condition monitoring card pairs | XMx16 and XIO16T | 620-002-000-113 |
| Condition monitoring module | XMV16 | 620-001-001-116 |
All VM products should be available in our expanded inventory, welcome to inquire:
