CE620 444-620-000-011-A1-B100-C01 Piezoelectric Accelerometer

  • product orgin:

    Sweden

  • brand:

    vibration
  • product details


CE620 444-620-000-011-A1-B100-C01 Piezoelectric Accelerometer

  • The CE620 piezoelectric accelerometer with integrated electronics from Meggitt’s vibro-meter® product line is a general-purpose vibration sensor designed for the monitoring and protection of machinery in harsh industrial environments.
  • The CE620 is an industry standard IEPE (integrated electronics piezo electric) vibration sensor that requires a constant current power supply and provides a dynamic vibration output signal (AC voltage) on a bias level (DC voltage). It is available with a sensitivity of either 100 or 500 mV/g.
  • The CE620 is available as a sensor only or fitted with an integral cable that is protected by a stainless-steel overbraid. Sensor only versions allow one of a range of different cable assemblies to be used to connect the sensor to the monitoring system, depending on the application and environment.
  • The CE620 is available in standard versions for use in standard (non-hazardous) areas and Ex versions for installation in hazardous areas
  • (potentially explosive atmospheres).
Picture of 444-620-000-111
