ABB PM866AK02 3BSE081637R1 AC800M Controllers

PM866AK02 controller kit including

CPU2
PM866A

Baseplate2
TP830

Terminator2
TB807

Expansion Cable1
TK850

Link cable1
TK851

Battery2
4943013-06

brand:
ABB

contact now download

product details

PM866AK02 3BSE081637R1

The PM866AK02 is a high-performance redundant controller in ABB's AC800M series, with the part number 3BSE081637R1. Below is a detailed introduction to it:

1. Performance Parameters

Processor: Features an MPC 866 processor with a clock frequency of 133MHz, capable of executing 1,000 Boolean operations in 0.09ms.
Memory: Has a total memory capacity of 64MB, of which 51.389MB is available for application programs. It also includes Flash memory for data storage.
Communication Interfaces: The controller backplane is equipped with 2 RJ45 Ethernet ports (CN1, CN2) for connecting to the control network, and 2 RJ45 serial ports (COM3, COM4). Among them, COM3 is an RS-232C port with modem control signals, and COM4 is used for connecting configuration tools.
Power Supply: Operates on 24V DC (19.2 - 30V DC), with a typical/maximum current consumption of 210/360mA and a power consumption of 5.1W (maximum 8.6W).

2. Key Features

Redundant Design: This module adopts a redundant design, featuring two identical analog output channels. Each channel can independently output analog signals, ensuring that if one channel fails, the other can continue to output signals to maintain normal system operation.
Analog Output: Equipped with 40 analog output channels that can output voltage or current signals. These output signals can be used to control various industrial equipment such as motors, valves, and pumps.
High Reliability: Manufactured using high-quality materials and processes, it can operate stably for a long time in harsh industrial environments. The redundant design further enhances the reliability of the system.
Strong Compatibility: Compatible with various industrial automation control systems and can connect to and control a wide range of equipment.
Easy Configuration & Maintenance: Users can customize and expand the module according to actual needs. The maintenance procedure is simple, allowing users to easily perform daily maintenance and cleaning, thereby reducing maintenance costs.

3. Application Fields

It is suitable for industrial automation control systems that require analog output, including specific fields such as oil and gas exploration & processing, power generation and energy management, chemical and pharmaceutical industries, water and wastewater treatment, and manufacturing automation.
